Stage Lighting Resources
for Your Next Project
Explore DUNDI stage lighting resources: product catalogs, user manuals, technical specifications and practical guides for theatre, broadcast, studio and film lighting. Use these resources to compare fixtures, review setup requirements and prepare your product inquiry.
01 / PRODUCT VIDEO LIBRARY
Stage Lighting Resources
Videos & Applications
See our stage lighting resources in action: individual fixture demonstrations, multi-product comparisons and real lighting scenes. Each video identifies the products and tested configurations so you can compare beam control, dimming and practical operation.
02 / THE DUNDI COLLECTION
Product Catalogs
Explore our stage lighting resources through the latest DUNDI catalog. Compare profile spotlights, Fresnel spotlights, studio panel lights, followspots and audience blinders, with product images, dimensions and technical specifications. Read online or download the complete PDF for your project team.
Latest Edition
October 2026
2026.10
English · 36 pages · PDF · 5.9 MB. Turn the pages below, zoom in for technical details, or download the complete catalog.
The catalog reader loads when this section is in view. You can also download the complete PDF above.
Catalog Archive
Browse earlier DUNDI product collections. Select an edition to open its catalog and explore our development through the years.
2019
2018
2017
2015
2014–2015
2013
2012
2010–2011Historical editions · Confirm current availability and specifications with our team.
03 / COMPARE THE DETAILS
Technical Specifications
These stage lighting resources include 18 PDF datasheets for DUNDI profile spotlights, Fresnel spotlights, studio panel lights and audience blinders. Select the exact configuration and compare optical performance, control options, electrical requirements, dimensions and weight where listed.
Profile Spotlights · 6 PDFs
01 / 6 PDF DATASHEETS
Profile Spotlights
Fixed-angle and zoom optics, with fixed-CCT, tunable-CCT and full-color configurations.
Fixed-CCT LED Fixed-Angle Profile Spotlight
Tunable-CCT LED Fixed-Angle Profile Spotlight
Full-Color LED Fixed-Angle Profile Spotlight
Fixed-CCT LED Zoom Profile Spotlight
Tunable-CCT LED Zoom Profile Spotlight
Full-Color LED Zoom Profile Spotlight
Fresnel Spotlights · 3 PDFs
02 / 3 PDF DATASHEETS
Fresnel Spotlights
Compare fixed-CCT, tunable-CCT and full-color broadcast and studio Fresnel specifications.
Fixed-CCT LED Broadcast & Studio Fresnel Spotlight
2700-6500K Tunable-CCT LED Broadcast & Studio Fresnel Spotlight
Full-Color LED Broadcast & Studio Fresnel Spotlight
Studio Panel Lights · 8 PDFs
03 / 8 PDF DATASHEETS
Studio Panel Lights
Explore broadcast and studio panel options by color configuration, CCT range and power class.
Fixed-CCT LED Broadcast & Studio Panel Light
2700-6200K Tunable-CCT LED Broadcast & Studio Panel Light
3200-5600K Tunable-CCT LED Broadcast & Studio Panel Light
Full-Color LED Broadcast & Studio Panel Light
400W Full-Color LED Broadcast & Studio Panel Light
600W Tunable-CCT LED Broadcast & Studio Panel Light
600W Full-Color LED Broadcast & Studio Panel Light
1000W Tunable-CCT LED Broadcast & Studio Panel Light
Stage Effect Lights · 1 PDF
04 / 1 PDF DATASHEET
Stage Effect Lights
Product specifications for the DD-SB4 4-Lite LED Audience Blinder.
4-Lite LED Audience Blinder DD-SB4
Choose the exact product configuration before comparing specifications. Each PDF opens in a new tab and can be saved from your browser. For project-specific photometric data or documents not listed here, contact DUNDI. For background on lighting control protocols, consult the ESTA Technical Standards Program; check each fixture manual for its supported functions.
04 / SETUP & OPERATION
User Manuals
Our stage lighting resources include user manuals for four full-color lighting configurations. Choose the matching fixture to review installation requirements, operating instructions and DMX channel settings. Check the model and document version before setup.
Profile Spotlights · 2 manuals
USER MANUAL · PDF
Full-Color LED Fixed-Angle Profile Spotlight
USER MANUAL · PDF
Full-Color LED Zoom Profile Spotlight
Fresnel Spotlights · 1 manual
USER MANUAL · PDF
Full-Color LED Broadcast & Studio Fresnel Spotlight
Studio Panel Lights · 1 manual
USER MANUAL · PDF
Full-Color LED Broadcast & Studio Panel Light
Need a different manual?
Use the manual matching your fixture configuration. Send the model number and, if available, the hardware or firmware version to DUNDI support for documents not listed here.
05 / KNOWLEDGE & INSIGHTS
Blog & Insights
Practical knowledge for selecting, specifying and operating professional stage and studio lighting.
Beam control, dimming & colour
Understand beam angle, framing shutters, edge definition and field uniformity. For camera work, compare colour rendering, colour temperature and flicker performance under the intended frame rate and dimming conditions.
Choose lighting for the space
Start with mounting height, throw distance, the area to illuminate and the required beam size. Theatre, television studios, film sets and live events each place different demands on optics, noise, control and rigging.
Check testing and documentation
DUNDI fixtures undergo 12 hours of full-power burn-in followed by approximately one hour of functional testing. Request the documentation applicable to the exact model and destination market; certificate scope can vary between products.
Define your fixture requirements
DUNDI supports OEM and ODM development from drawings or samples. Share optical requirements, power supply, control functions, mechanical dimensions, branding and order quantity so our team can assess feasibility and prepare a quotation.
How to Use Our Stage Lighting Resources
Choose the right document at each stage, from product selection to fixture setup. The guide below explains how our stage lighting resources work together for procurement, project planning and technical support.
01 / Explore the range
Start with the latest product catalog when you are comparing fixture families or preparing an initial shortlist. It brings product images and key specifications together so distributors, designers and project teams can discuss suitable options. Use earlier editions as a record of product development; confirm current availability before specifying a model.
02 / Compare exact configurations
Open the technical datasheet for the configuration you need. Check beam angle or zoom range, light-source configuration, power requirements, control options, dimensions and weight where provided. Fixed-CCT, tunable-CCT and full-color versions may have different specifications even when their housings look similar. Compare matching versions rather than relying on product photographs alone.
03 / Review setup and operation
Use the user manual to prepare installation and operation. Match the fixture model and document version, then check the relevant mounting instructions, power connections, controls and DMX channel modes. A datasheet helps with selection; the manual explains how the matching fixture is operated. Follow the product instructions and use qualified personnel where required.
04 / Watch, then confirm
Use product videos to review controls, framing, zoom, dimming and application demonstrations. Camera exposure, white balance, viewing distance and the playback screen affect the appearance of recorded light. Combine video observations with the relevant technical documents, and send your throw distance, mounting height and intended use when requesting a recommendation.
Frequently Asked Questions
Find practical answers about selecting, downloading and using DUNDI product documentation.
Which stage lighting resources should I use first?
Begin with the catalog to identify a product family, then use the matching datasheet to compare technical requirements. Review the user manual before installation or programming, and watch the relevant video for a practical demonstration. This sequence helps your purchasing and technical teams work from the same product configuration.
What is the difference between a datasheet and a user manual?
A datasheet summarizes a fixture’s technical characteristics for selection and specification. A user manual explains installation, controls, operating modes and other model-specific instructions. Keep both documents with your project records, and check that they refer to the same fixture version. Neither document should be substituted for the other.
How do I choose the correct document for my fixture?
Match the model number on the fixture label with the document title. Also check the light-source or color configuration, optical version and any hardware or firmware information listed. If the match is unclear, send DUNDI a photograph of the product label and the document you are using before proceeding.
Can I download the complete catalog and individual PDFs?
Yes. Select Download Full Catalog in the catalog section to save the complete latest edition. In the specifications and manuals sections, choose the matching product’s PDF link, then use your browser’s download control. Save the edition or revision information with each document so your team can identify the version being reviewed.
Do product videos replace photometric data or technical specifications?
No. Videos show product operation and selected lighting effects, but they do not establish measured output or guarantee how a fixture will appear in your venue. Use the matching technical information for specification decisions. For camera applications, share your intended frame rate and dimming requirements when asking about suitability.
What if I cannot find a manual or need project-specific information?
Contact DUNDI with the model number, intended application and destination market. Include the required quantity, throw distance, mounting height and control requirements where relevant. Tell us which stage lighting resources or additional measurements you need; our team will confirm the applicable documents and available information for that configuration.
Need the Right Document?
Need additional stage lighting resources for your project? Send us your fixture model, application and destination market. Our team can help locate the relevant datasheet, user manual or catalog and discuss suitable product options.
